- testo 400 universal IAQ instrument, silicone hoses, mains unit with USB cable, calibration protocol, instruction manual (0560 0400)
- CO2 probe with Bluetooth® including temperature and humidity sensor (consisting of CO2 probe head and Bluetooth® handle), 4 x AA batteries, table stand and calibration protocol (0632 1551) Please do not use the probe in condensing atmospheres. For continuous application in high-humidity ranges
> 80% RH at ≤ 30 °C for > 12 h
> 60% RH at > 30 °C for > 12 h
Please get in touch with Testo Service or contact us via the Testo website - Turbulence probe with fixed cable and calibration protocol (0628 0152)
- Globe thermometer (Ø 150 mm, TC type K) with fixed cable (0602 0743)
- Measuring tripod for comfort level measurements, consisting of a folding stand, mounting rod, handheld instrument holder, 4 x probe mounts, including bag (0554 1591)
- Transport case for IAQ and comfort level measurements (0516 2400)
testo 400 IAQ and comfort kit with tripod
SKU: 0563 0401
- Standard-compliant determination of the comfort level: PMV and PPD as well as draught and turbulence as per EN ISO 7730 and ASHRAE 55
- Monitor the indoor air quality: Determination of CO2Â concentration, humidity, air temperature and turbulence in workplaces, including long-term measurements
- Smart, intuitive measurement programs, complete your measurement with full documentation on site at the customer’s premises or carry out further analysis using the testo DataControl measurement data management and analysis software
- In the kit: testo 400 universal IAQ instrument, CO2 probe (with Bluetooth® handle), turbulence probe with cable, globe thermometer (Ø 150 mm) with cable, measuring tripod with bag, case
- Standard-compliant determination of the comfort level: PMV and PPD as well as draught and turbulence as per EN ISO 7730 and ASHRAE 55
- Monitor the indoor air quality: Determination of CO2Â concentration, humidity, air temperature and turbulence in workplaces, including long-term measurements
- Smart, intuitive measurement programs, complete your measurement with full documentation on site at the customer’s premises or carry out further analysis using the testo DataControl measurement data management and analysis software
- In the kit: testo 400 universal IAQ instrument, CO2 probe (with Bluetooth® handle), turbulence probe with cable, globe thermometer (Ø 150 mm) with cable, measuring tripod with bag, case
Ideal kit for IAQ professionals, with a focus on indoor air quality and comfort level. You will receive the testo 400 universal IAQ measuring instrument with intuitive measurement menus, one COâ‚‚ probe (with Bluetooth® handle), one turbulence probe and one globe thermometer Ø 150 mm (both with fixed cable). Use the measuring tripod to ensure standard-compliant positioning of the probes. In combination with the IAQ data logger, which is available to order separately, long-term measurements up to 2 weeks can be recorded, even without the IAQ measuring instrument.
*All prices include GST
Loading...
Description
Ideal kit for IAQ professionals, with a focus on indoor air quality and comfort level. You will receive the testo 400 universal IAQ measuring instrument with intuitive measurement menus, one CO₂ probe (with Bluetooth® handle), one turbulence probe and one globe thermometer Ø 150 mm (both with fixed cable). Use the measuring tripod to ensure standard-compliant positioning of the probes. In combination with the IAQ data logger, which is available to order separately, long-term measurements up to 2 weeks can be recorded, even without the IAQ measuring instrument.
Delivery Scope
Technical Data
| Temperature - NTC | |
|---|---|
| Measuring range | -40 to +150 °C |
| Accuracy | ±0.2 °C ±1 Digit (-25 to +74.9 °C)
±0.4 °C ±1 Digit (-40 to -25.1 °C) ±0.4 °C ±1 Digit (+75 to +99.9 °C) ±0.5 % of mv ±1 Digit (Remaining Range) |
| Resolution | 0.1 °C |
| Temperature - TC Type K (NiCr-Ni) | |
| Measuring range | -200 to +1370 °C |
| Accuracy | ±(0.3 °C + 0.1 % of mv) ±1 Digit |
| Resolution | 0.1 °C |
| Differential pressure (internal sensor) - Piezoresistive | |
| Measuring range | 0 to +200 hPa |
| Accuracy | ±(0.3 Pa + 1 % of mv) ±1 Digit (0 to 25 hPa)
±(0.1 hPa + 1.5 % of mv) ±1 Digit (25.001 to 200 hPa) |
| Resolution | 0.001 hPa |
| Absolute Pressure (internal sensor and external probe) | |
| Measuring range | 700 to 1100 hPa |
| Accuracy | ±3 hPa |
| Resolution | 0.1 hPa |
| General technical data | |
| Weight | 510 g (instrument) |
| Dimensions | 210 x 95 x 39 mm ((LxWxH)) |
| Operating temperature | -5 to +45 °C |
| Product-/housing material | Plastic |
| Protection class | IP40 |
| Connectable probes | 4 x digital Bluetooth® probe or testo Smart Probe; 2 x digital probe with fixed cable or temperature probe NTC with fixed cable (via Testo Universal Connector - TUC); 2 x temperature probe TC type K with fixed cable |
| Product colour | black/orange |
| Camera image size | Main camera: 8.0 MP; Front camera: 5.0 MP |
| Battery life | approx. 10 hrs continuous operation |
| Display type | 5.0" touch display, HD 1280*720 pixels, IPS (160 k) |
| Power supply | Rechargeable li-ion battery (5550 mAh) |
| Interface | Bluetooth®; USB; WLAN |
| Memory | 2 GB; 1,000,000 measuring values |
| Storage temperature | -20 to +60 °C |
Applications
IAQ measurements in the field of air conditioning and ventilation
- High-precision, location-independent and built-in differential pressure sensor, smart and intuitive measurement programs for IAQ measurements in accordance with the standards, creation of documentation on site, e-mailing of reports, versatile combination options with IAQ probes
IAQ measurements in the field of air conditioning and ventilation
Custom-combine your Testo IAQ measuring instrument with IAQ probes and accessories for your application.
With the right products, you can handle all kinds of IAQ applications:
- Air flow measurements: Flow measurements in ducts, at outlets and on filters as per EN ISO 12599 and ASHRAE 111
- Comfort level measurements: Measurement of indoor air quality or turbulence as per EN ISO 7730 and ASHRAE 55, NET measurement as per DIN 33403, PMV/PPD as per EN ISO 7730 and ASHRAE 55, WBGT measurement as per DIN 33403 and EN ISO 7243
- Measurements in laboratories and cleanrooms: Flow measurements in fume cupboards as per DIN EN 14175-3/-4, differential pressure measurements and laminar flow measurements in cleanrooms, humidity measurements in cleanrooms
